Automotive electronic components screening（AEC-Q100/Q101/Q200认证）

Chrysler, Ford and General Motors set up the Automotive Electronics Commission (AEC) to establish a set of general parts qualification and quality system standards. AEC established quality control standards. At the same time, the AEC-compliant parts can be used by the three automobile factories at the same time, which promotes the willingness of parts manufacturers to exchange their product characteristics data, and promotes the implementation of the generality of automobile parts, laying the foundation for the rapid growth of automobile parts market.



Certification standard for stress testing of EC-Q100 chip

AEC-Q100-001 Bond line shear stress test

AEC-Q100-002 Electrostatic discharge test in human body mode

AEC-Q100-003 Mechanical mode electrostatic discharge test

AEC-Q100-004 Integrated circuit latch up test

AEC-Q100-005 Write able erasable permanent memory durability, data retention and working life testing.

AEC-Q100-006 Test of parasitic gate leakage current caused by thermoelectric effect

AEC-Q100-007 Fault simulation and test level

AEC-Q100-008 Life cycle failure rate（ELFR）

AEC-Q100-009 Assessment of electrical distribution

AEC-Q100-010 Solder ball shear test

AEC-Q100-011 Electrostatic discharge test in charged device mode

AEC-Q100-012 Short circuit reliability description of sensitive power equipment for 12V system



AEC-Q101 Authentication specification for discrete component stress testing (Stress Test) (Automotive semiconductor discrete device)

AEC - Q101-001 Electrostatic discharge test in human body mode

AEC - Q101-002 Mechanical mode electrostatic discharge test

AEC - Q101-003 Bond line shear stress test

AEC - Q101-004 Synchronization test method

AEC - Q101-005 Electrostatic discharge test in charged device mode

AEC - Q101-006 Short circuit reliability description of sensitive power equipment for 12V system



AEC-Q200 Authentication specification for passive component stress testing (Stress Test) (passive device)

AEC-Q200-001 Flame retardancy test

AEC-Q200-002 Electrostatic discharge test in human body mode

AEC-Q200-003 Beam load and fracture strength

AEC-Q200-004 Self recovery fuse measuring program

AEC-Q200-005 Plate bending test

AEC-Q200-006 Shear strength test after surface mount

AEC-Q200-007 Surge test
